Hardware
|
Ethernet Standards
|
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
|
Interface
|
1 × RJ11 ADSL Port,
4×10/100Mbps Auto MDI/MDIX RJ45 LAN Port
(Optional Ethernet WAN for LAN4)
|
LED
|
PWR, LAN4, LAN3, LAN2, LAN1, WLAN, WPS, ADSL, Internet
|
Power Supply
|
DC 12V/500mA(Output)
|
Button
|
WPS, Default, Power ON/OFF
|
Dimensions (L x W x H )
|
144.5mm ×90mm× 26.5 mm
|
Software
|
ADSL Version
|
ADSL, ADSL2, ADSL2+
|
Data Rate
|
Downstream: Up to 24Mbps
Upstream: Up to 1Mbps
|
ATM / PPP Protocol
|
ATM Forum UNI3.1/4.0 PVC (up to 8PVCs)
ATM Adaptation Layer Type 5 (AAL5)
ATM QoS
Bridged and Routed Ethernet Encapsulation
VC and LLC Based Multiplexing
PPP over Ethernet (RFC2516)
PPP over ATM (RFC 2364)
IPoA (RFC1577/2225)
|
Main Feature
|
DHCP, DHCP Relay
NAT, Static Routing
VPN (PPTP, L2TP, IPsec) Pass-through
PVC/Ethernet Port Mapping
DNS Relay, DDNS
IGMP Multicast, IGMP Snooping V1/V2
Virtual Server, DMZ, ACL (Access Control List)
UPnP
IPv6
|
Management
|
Web Based Configuration (HTTP), Remote Management,
Telnet Management, Command Line Interface,
TR-069, SNMP, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools
|
Wireless Standards
|
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
|
Frequency Range
|
2.4-2.4835GHz
|
Wireless Speed
|
Up to 300Mbps
|
Wireless Security
|
WEP 64/128bits,
WPA(TKIP/AES)/WPA2(TKIP/AES)/WPA2 Mixed,
802.1x Authentication
Wireless MAC Filtering
|
Wireless Security Power
|
20dBm
|
Antenna Type
|
2× 5dBi Antennas
|
Others
|
Certification
|
CE, FCC
|
Environment
|
Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90%RH non-condensing
Storage Humidity: 5%~90%RH non-condensing
|
Package
|
1 × DL4323
1 × 12V/500mA Power Adapter
2 × RJ11 Telephone Cable
1 × RJ45 Ethernet Cable
1 × ADSL Splitter
1 × Quick Installation Guide (Multilingual)
|
